Printing resolution dpi
4800* horizontal X 1200 vertical * Ink droplets can be placed with a pitch of 1/4800 inch at minimum.
Interface
USB Port: Hi-Speed USB *1 LAN Port: Wireless LAN: IEEE802.11n/IEEE802.11g/IEEE802.11b *2 *1 A computer that complies with Hi-Speed USB standard is required. Since the Hi-Speed USB interface is fully upwardly compatible with USB 1.1, it can be used at USB 1.1. *2 Setup possible through Standard setup, WPS Wi-Fi Protected Setup or WCN Windows Connect Now.
Print width
8 inches/203.2 mm for Borderless Printing: 8.5 inches/216 mm
Operating environment
Temperature: 5 to 35 °C 41 to 95 °F Humidity: 10 to 90 % RH no condensation
Storage environment
Temperature: 0 to 40 °C 32 to 104 °F Humidity: 5 to 95 % RH no condensation
Power supply
AC 100-240 V, 50/60 Hz
Power consumption
Printing Copy: Approx. 19 W Standby minimum: Approx. 0.7 W *1*2 OFF: Approx. 0.2 W *1 *1 USB connection to PC *2 The wait time for standby cannot be changed.
External dimensions
Approx. 17.7 W X 12 D X 6 H inches Approx. 449 W X 304 D X 152 H mm * With the Front Cover retracted.
Weight
Approx. 5.7 kg Approx. 12.4 lb * With the FINE Cartridges installed.
Canon FINE Cartridge
Total 1792 nozzles BK 640 nozzles, C/M/Y each 384 nozzles
Copy Specifications
Multiple copy
max. 99 pages
Intensity adjustment
9 positions, Auto intensity AE copy
Reduction/Enlargement
25 % - 400 % 1 % unit
Scan Specifications
Scanner driver
TWAIN 1.9 Specification/WIA for Windows 7/Windows Vista/Windows XP
Maximum scanning size
A4/Letter, 8.5" X 11.7"/216 X 297 mm
Scanning resolution
Optical resolution horizontal X vertical max: 1200 X 2400 dpi *1 Interpolated resolution max: 19200 X 19200 dpi *2 *1 Optical Resolution represents the maximum sampling rate based on ISO 14473. *2 Increasing the scanning resolution will limit the maximum possible scanning area.
Gradation Input/Output
Gray: 16 bit/8 bit Color: 48 bit/24 bit RGB each 16 bit/8 bit
