Maximum Printing Resolution
9600 horizontal*1x 2400 vertical dpi
Print Head / Ink
Type:
Individual Ink Tank
Number of Nozzles:
Total 5,120 nozzles
Ink Droplet Size:
1pl
Ink Tank:
PGI-750 Pigment Black, CLI-751 Cyan / Magenta / Yellow / Black
[Optional: PGI-755 XXL Pigment Black, PGI-750XL Pigment Black,
CLI-751XL Cyan / Magenta / Yellow / Black]
Print Speed*2
Based on ISO / IEC 24734.
Clickherefor summary report
Clickherefor Document Print and Copy Speed Measurement Conditions
Document: Col
ESAT / Simplex
approx. 10.4ipm
Document: B/W
ESAT / Simplex
approx. 14.5ipm
Photo 11 x 14" image
PP-201
approx. 120secs.
Photo 4 x 6"
PP-201 / Borderless
approx. 36secs.
Printable Width
Up to 322.2mm 12.7 inch, Borderless: Up to 329mm 13 inch
Printable Area
Borderless Printing*3
Top / Bottom / Right / Left margin: each 0mm Supported Paper Size: A3+, A3, A4, LTR, LDR, 4 x 6", 5 x 7", 8 x 10", 10 x 12"
Bordered Printing
Top margin: 3mm, Bottom margin: 5mm,
Left / Right margin: each 3.4mm LTR / LGL: Left: 6.4mm, Right: 6.3mm
Recommended Printing Area
Top margin: 40.7mm / Bottom margin: 37.4mm
Paper Size
A3+, A3, A4, A5, B4, B5, LTR, LGL, LDR, 4 x 6", 5 x 7", 8 x 10", 10 x 12", Envelopes DL, COM10, Custum size width 55 - 329mm, length 91 - 676mm
Paper Handling Rear Tray
Maximum Number
Plain Paper
A3, A4, A5, B4, B5, LTR, LGL, LDR = 150
High Resolution Paper HR-101N
A3+ = 20, A3 = 50, A4 = 80
Photo Paper Pro Platinum PT-101
A3+ = 1, A3, A4 = 10, 4 x 6" = 20
Photo Paper Plus Glossy II PP-201
A3+ = 1, A3, A4 = 10, 4 x 6" = 20
Photo Paper Pro Luster LU-101
A3+ = 1, A3, A4 = 10
Photo Paper Plus Semi-Gloss SG-201
A3+ = 1, A3, A4, 8 x 10" = 10, 4 x 6" = 20
Glossy Photo Paper "Everyday Use" GP-601
A4 = 10, 4 x 6" = 20
Matte Photo Paper MP-101
A3, A4 = 10, 4 x 6" = 20
Envelope
European DL / US Com. #10 = 10
Paper Weight
Front Tray
Plain Paper: 64 - 105g/m2, Canon specialty paper: max paper weight: approx. 300g/m2Photo Paper Pro Platinum PT-101
Ink End Sensor
Optical sensor + Dot count
Print Head Alignment
Auto / Manual
Network
Protocol
TCP / IP
Wired LAN
Network Type
IEEE 802.3u (100BASE-TX) / IEEE 802.3 (10BASE-T)
Data Rate
10M / 100Mbps auto switchable
Wireless LAN
Network Type
IEEE 802.11n / IEEE 802.11g / IEEE 802.11b
Frequency Band
2.4GHz
Channel*4
1 - 13
Range
indoor 50m depends on the transmission speed and conditions
Security
WEP 64 / 128-bit, WPA-PSK TKIP / AES, WPA2-PSK TKIP / AES
System Requirements
Windows:
Please check OS compatibility and to download the latest driver updates.
Windows 8 / Windows 7 / Windows XP / Windows Vista
Macintosh:
Mac OS X v10.6.8 and later
General Specifications
Interface
Wireless LAN IEEE 802.11b/g/n, 100 Base-TX / 10 Base-T, USB 2.0 Hi-Speed
Apple AirPrint
Available
Google Cloud Print
Available
PIXMA Printing Solutions
Available
Operating Environment
Temperature: 15 - 30°C Humidity: 10 - 80% RH no dew condensation
Storage Environment
Temperature: 0 - 40°C Humidity: 5 - 95%RH no dew condensation
Acoustic Noise PC Print
Photo 4 x 6"*5
approx. 44.0dBA
Power
AC 100 - 240V 50 / 60Hz
Power Consumption
Standby
Wireless LAN connection to PC
Approx. 2.0W
OFF:
Approx. 0.3W
Printing*6
Wireless LAN connection to PC
Approx. 24W
Environment
Regulation:
RoHS EU, China, WEEE EU
Eco-Label:
Energy Star, EPEAT
Duty Cycle
up to 12,000 pages/month
Dimension W x D x H
approx. 584 x 310 x 159mm
Weight
approx. 8.1kg
